Product Description
Oxy-hydrogen gas generator is only using electricity and pure water. It is an economical and practical energy-saving gas generation equipment. The cost of electricity and water reduces by more than 40%, it saves energy by more than 30% compared with LPG, Propane, and Acetylene fuel.
Unique Structure and Function Design
1. Radiator-type electrolyzer. Aluminum tube heat dissipation with strong heat dissipation capacity and high efficiency of water electrolysis. It is a flange-type joint, which can be disassembled for thorough maintenance in later, and is suitable for large-flow gas production.
2. Industrial-type equipment. It can meet the requirements of a long time of uninterrupted work, and can additionally add external automatic water feeding to realize 24 hours of continuous work.
3. Easy operation display screen. It displays image and text dynamic functions, water shortage, and fault alarms.
Technical Parameter
(The model number refers to the gas output of the oxyhydrogen generator, unit: L/h)
| Model | OH10000 |
| AC Voltage(V) | 380, three phases |
| Rated Power(KW) | 31 |
| Gas Output(L/h) | 0-10000 |
| Working Pressure(Mpa) | 0.1-0.2 |
| Max Water Consumption(L/h) | 5.6 |
| Water Feed | auto |
| Dimension(L*W*H-mm) | 1500*670*1800 |
| Weight(kg) | 610 |
| Ventilation Space Requirement(mm) | 400 |
Standard Accessories List
1*electronic flame arrester,1*flame torch, and 3m blue gas tube;
Note: the package does not contain the electrolyte powder(KOH), you can buy it locally.
