About Okay Energy Technology of HHO Generator
1 Patented Integration of Water Electrolysis Cell Forming
Our electrolysis cell integration is used in Large Module in order to make sure no Leakage, explosion-proof, and long life cycle.
2 Patented Electrolysis Power Supply Based SCM
Our power supply is specially designed for electrolysis.
3 Patented Multi-layer Anti-fire Water Seal Technology
Water seal device is important unit of jewelry welding torch, this unit is designed for backfire-proof, It works 100% OK.
Technical Parameter
(The model number refers to the gas output of the oxyhydrogen generator, unit: L/h)
| Model | OH7500 |
| AC Voltage(V) | 380, three phases |
| Rated Power(KW) | 23 |
| Gas Output(L/h) | 0-7500 |
| Working Pressure(Mpa) | 0.1-0.2 |
| Max Water Consumption(L/h) | 4 |
| Water Feed | auto |
| Dimension(L*W*H-mm) | 1350*670*1800 |
| Weight(kg) | 552 |
| Ventilation Space Requirement(mm) | 400 |
Standard Accessories List
1*electronic flame arrester,1*flame torch, and 3m blue gas tube;
Note: the package does not contain the electrolyte powder(KOH), you can buy it locally.
