Product Description
Heavy-duty oxyhydrogen generators have several unique five systems including the integrated electrolysis cell with the function of water electrolysis, cooling, water and gas separation, IGBT power supply system, wet and dry anti-backfire safety system, and PLC control panel system. According to the requirement of your project, Okay Energy's engineer will provide a customized solution and matched accessories to ensure economical practicability to realize the greatest value.
Technical Parameter
(The model number refers to the gas output of the oxyhydrogen generator, unit: L/h)
| Model | OH5500 |
| AC Voltage(V) | 380,three phases |
| Rated Power(KW) | 17 |
| Gas Output(L/h) | 0-5500 |
| Working Pressure(Mpa) | 0.1-0.2 |
| Max Water Consumption(L/h) | 2.8 |
| Water Feed | auto |
| Dimension(L*W*H-mm) | 1200*670*1700 |
| Weight(kg) | 396 |
| Ventilation Space Requirement(mm) | 400 |
Standard Accessories List
1*electronic flame arrester,1*flame torch, and 3m blue gas tube;
Note: the package does not contain the electrolyte powder(KOH), you can buy it locally.
