Product Description
The pure water hydrogen generator electrolyzes pure water with SPE technology to produce high-purity hydrogen. The SPE electrodes, as the core of the product, are highly active catalytic electrode with nearly zero distance between the electrodes , which is formed by integrating composite catalyst with and ion membrane with high electrolytic efficiency.
Technical Parameter
| Model | HL3000 |
| Production Rate | 3000ml/min |
| Purity of Hydrogen | 99.999% |
| Output Pressure | 0.4Mpa |
| AC Voltage | 220V |
| Power | <1500W |
| Used Water | deionized water or distilled water less than 1MΩ/cm |
| Dimension(L*W*H-mm) | 550*400*760 |
| Weight | 50kg |
Product Features
1. It can replace the high-pressure hydrogen cylinder, ensure the laboratory instrument safety.
2. International advanced "SPE" technology (solid state electrolysis technology).
3. Electrolyte pure water directly without adding alkali, with high electrolytic rate and sufficient gas production.
4. Imported polymer ionic membrane with original material from the United States.
5. Electrolytic cell: aviation titanium alloy material with iridium and tantalum coating.
