The Principle Of Oxyhydrogen Generator
The water molecule (H2O) is decomposed into oxygen and hydrogen through electrolysis. Hydrogen and oxygen gas are mixed gases with the radio of 2:1. Hydrogen can be combusted. Oxygen gas helps to combust with hydrogen gas to form a hydrogen-oxygen flame.
The OH800’s electrolytic cell adopts the principle of bellows-type heat dissipation, which is small in size and easy to maintain. The user should maintain the electrolytic cell after 500 hours of running.
Okay Energy Oxyhydrogen Generators Compared With Other Brands of Oxyhydrogen Generators
| Okay Energy Oxyhydrogen Generators | Other Brands Of Oxyhydrogen Generators | |
| Production Capacity |
There are small and large machines to meet different gas production requirements. |
Some only have small gas production equipment, and some others only produce medium and large scale equipment. |
| Equipment Safety |
Auxiliary water tank is built-in the equipment to protect the electrolytic cell from burning out |
No water tank or the water tank is made of plastic materials. |
| Anti Backfire System |
The flame torch is with anti-backfire function. Electronic flame arrestor for OH800-OH20000 machine. |
The flame torch has no flame arrestor. There is no electronic flame arrestor for large machines. |
| Electrolytic Cell |
OH800-OH1000 machine is made of the integrated forming spiral electrolytic cell, so it is much better for electrolysis and radiating. |
The electrolytic cell is relatively simple, the radiator is relatively small, and the heat dissipation effect is poor. |
Technical Parameter
| Model | OH800 |
| AC Voltage | 220V |
| Rated Power(KW) | 3 |
| Gas Output(L/h) | 0-800L/h |
| Working Pressure | 0.1-0.2Mpa |
| Max Water Consumption(L/h) | 0.43 |
| Water Feed | manual |
| Dimension(L*W*H-mm) | 660*550*800 |
| Weight(kg) | 70 |
| Ventilation Space Requirement(mm) | 200 |
Standard Accessories List
1*electronic flame arrester,1*flame torch, and 3m blue gas tube;
Note: the package does not contain the electrolyte powder(KOH), you can buy it locally.
We can provide a centralized gas supply scheme, special accessories, OEM, or ODM service according to the project.
