Water Fuel Oxy Hydrogen Generator With 400 Lph Oxygen Hydrogen Torch

1set
MOQ
USD1950-USD2050
Price
Water Fuel Oxy Hydrogen Generator With 400 Lph Oxygen Hydrogen Torch
Features Gallery Product Description Request A Quote
Features
Specifications
AC Voltage: 110/220V
Production Rate: 400L/h
Working Pressure: 0.1-0.14Mpa
Working Medium: Pure Water,deionized Water Or Distilled Water
Dimension(L*W*H): 695*246*470mm
Net Weight: 26kg
Max. Water Consuption: 0.23L/h
Water Feed: Manual
Highlight:

Water Fuel Oxy Hydrogen Generator

,

Oxy Hydrogen Generator 400 Lph

Basic Infomation
Place of Origin: Hunan,China
Brand Name: Okay Energy
Certification: CE, ISO9001
Model Number: OH400
Payment & Shipping Terms
Packaging Details: Standard export carton,1set/carton
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, Credit Card
Supply Ability: 200 sets per month
Product Description

Water Fuel Oxy Hydrogen Flame Generator OH400 1.4KW portable type

Product Description

OH400 oxy-hydrogen generator’s core parts include pressure gauge, pressure control switch, auxiliary tank,electrolyzer,power supply and anti-backfire flame arrester.

1. Pressure gauge: reading and displaying real-time pressure value.

2. Pressure control switch: stop gas production due to over pressure,and automatically resume gas production due to low pressure.

3. Auxiliary tank: it is also called filter tank. Pure water is added in the tank to filter hho gas. Alcohol or petroleum ether can be added to diffuse the oxyhydrogen flame and reduce the flame temperature.

4. Electrolyzer: independent multiple cylinder electrolytic cells.For OH400 machine,there are four cells.One electrolytic cell produces 100L hho gas.

5. Power supply: one electrolytic cell corresponds to one power supply.

6. Anti-backfire flame arrestor: as the combustion speed of oxyhydrogen gas is fast,and the speed is 13m/s. The dry type flame arrestor of OH400 machine adopts the principle of hho gas only flowing out but not flowing in the gas tube, which can prevent flame from flowing back when backfire accurs.



Technical Parameter

(The model number refers to the gas output of the oxyhydrogen generator, unit: L/h)

Model OH400
AC Voltage(V) 220/110
Rated Power(KW) 1.4
Gas Output(L/h) 0-400
Working Pressure 0.1-0.14Mpa
Max. Water Consumption(L/h) 0.23
Water Feed manual
Dimension(L*W*H-mm) 695*246*470
Weight(kg) 26
Vertilation Space Requirement(mm) 200



Standard Accessories List

A box of a flame torch, 2* transparent gas tubes, and 1*flame arrester

Note: the package does not contain the electrolyte powder(KOH), you can buy it locally.
