Product Description
Due to the low efficiency and high cost of PEM water electrolysis,the industrial oxyhydrogen generators adopt the alkaline electrolysis method. Generally,25%-28% concentration of potassium hydroxide(KOH) or sodium hydroxide(NaOH) is used to improve the electrolysis efficiency. Our HHO machine only add electrolyte before the first time to use. Only purified water,distilled water or deionized water are added for the continuous use later. After the machine is running 500 hours,it should replace the electrolyte,clean and maintain the machine.
Technical Parameter
(The model number refers to the gas output of the oxyhydrogen generator, unit: L/h)
| Model | OH300 |
| AC Voltage(V) | 220/110 |
| Rated Power(KW) | 1.2 |
| Gas Output(L/h) | 0-300 |
| Working Pressure | 0.1-0.14Mpa |
| Max. Water Consumption(L/h) | 0.17 |
| Water Feed | manual |
| Dimension(L*W*H-mm) | 575*246*470 |
| Weight(kg) | 23 |
| Vertilation Space Requirement(mm) | 200 |
Standard Accessories List
A box of a flame torch, 2* transparent gas tubes, and 1*flame arrester
Note: the package does not contain the electrolyte powder(KOH), you can buy it locally.
