Product Description
1. Convenient operation: hho gas is produced when the machine is powered on. No gas cylinder is needed as long as water and electricity are available.
2. Gas supply on demand: turn on the power for 10 seconds to supply gas, and produce as much as you need. The gas production can be adjusted as much as you need.
3. Non-toxic and tasteless: hydrogen and oxygen are non-toxic and tasteless gases, with no risk of poisoning.
4. Safety operation: the oxyhydrogen generator has no gas storage, and is ready for use when it is produced. The machine has an over-pressure protection device. Unlike the high-pressure gas cylinder, the oxyhydrogen generator has six anti-backfire devices and 100% effective anti-tempering caused by operation errors.
5. Flame concentration: the oxyhydrogen flame is concentrated, suitable for precision flame processing. The heating speed is fast, and the operation efficiency is high.
6. Multiple guarantees: built-in leakage protection, over-current protection, over-temperature protection, water shortage protection, and over-voltage protection.
Technical Parameter
(The model number refers to the gas output of the oxyhydrogen generator, unit: L/h)
| Model | OH200 |
| AC Voltage(V) | 220/110 |
| Rated Power(KW) | 0.8 |
| Gas Output(L/h) | 0-200 |
| Working Pressure | 0.1-0.14Mpa |
| Max. Water Consumption(L/h) | 0.11 |
| Water Feed | manual |
| Dimension(L*W*H-mm) | 450*246*470 |
| Weight(kg) | 17 |
| Vertilation Space Requirement(mm) | 200 |
Standard Accessories List
A box of a flame torch, 2* transparent gas tubes, and 1*flame arrester
Note: the package does not contain the electrolyte powder(KOH), you can buy it locally.
