Product Description
Outstanding process design can not only guarantee the production water quality but also reduce the cost of consumable items.
A.High quality core components, like reverse osmosis membrane, refined mixed and polished resin, can best ensure the production water quality.
B.Standardized and parametric CAD product design method makes water purification system has reasonable structure, strong interchangeability and stable quality.
C.through adopting safe 24V direct current power supply, the machine Power Consumption will be only a few dozen watts per hour.
D.Through monitoring production water quality on line and displaying by LCD screen in real time, accurate and intuitive production water information can be observed directly.
E.By adopting pressure closed design and pipeline, joint with inert material( like PE, POM) to avoid the secondary pollution.
F.Pressure closed system design .
G.Automatic water production and storage.
H.The machine can output RO pure water and UP ultra-pure water at the same time. Water draw rate is about 1.5 liters/minute when water tank has storage.
I.Original separation design make it possible that we can install external water valve in any position of lab building. One machine and more water points makes it more convenient.
Technical Parameter
| Type | Comprehensive Analytical Type |
| Model | OK-EP20VF |
| AC Voltage | 110/220V,50/60Hz |
| Flow Rate | 1.5-2L/min |
| Output | 20L/h |
| Feed Water Requirements | Tap water, temperature 10~35℃,pressure 0.15-0.35Mpa;TDS:≤200mg/L |
| Water Quality | |
| Type 2 Pure Water | Conductivity:2-10μs/cm@25℃ |
| Type 1 Ultra-pure Water |
Resistivity:18.25MΩ/cm@25℃, TOC:1-3ppb, Bacteria: <1CFU/ml, Particle: (>0.2μm) <1pc/ml |
| If UV or Not | Yes.UV lamp to get rid of bacterial spores |
| If Ultrafiltration or Not | Yes.Ultrafiltration to pyrogen removal |
| Application |
Molecular biology, life science, gene research, tissue culture, test tube baby, bioengineering, animal and plant cell culture, DNA, monoclonal antibody research, etc. |
|
Dimension(L*W*H-mm) |
410*300*500 |
|
Weight(kg) |
30 |
| Consumable Cartridge |
Including a standard cartridge PP filter, activated carbon filter, |
| Maintenance and Tips |
Generally,change it every 6months(PP filter,actived carbon filter)and replace it when resistivity ≤ 10MΩ.CM(iox exchange column) |
Laboratory Water Purifier
Type 1 Ultra Pure Water
• Applications:
• Analysis of organic and inorganic traces
• Chromatography
• Mass spectrometry
• UV-visible spectrophotometry
• Microbiology
Type 2 Pure Water
• Applications:
• Media preparation
• Preparation of buffers
• Washing and rinsing of glassware
• Preparation of chemical reagents
• Ultrafiltration equipment washing
Ordering Information
