Machine Performance of Alkaline Hydrogen Water Ionizer Machine
1. Using an Advanced touch control panel technology, the system uses E-valve to control the water source.
2. Includes a Super large 3.8-inch LCD colorful screen,the LCD Displays ORP ,PH,flow rate,temperature and process of the water.
3. The Microcomputer automatic control system for the electrolysis makes the water TDS from 50 to 1500PPM.
4. This lonizer has 8 Super- large titanium- platinum coated plates(Total surface area is more than 1600cm)which increases usage life. System also has self-cleaning function.
5. Ph levels are from 2.5 to 11.2 and ORP level from +500mv to-800mv.
6. Uses high-power SMPS power supply , the voltage is from 110V to 240V universal and is very safe and reliable. The system also has a built-in overheating radiator and continuous work function.
Technical Parameter
| Model | AW-929 |
| AC Voltage |
AC220V, 50Hz or 110v,60HZ |
| ELectrolyzing Power | 210W~8W |
| Standby Power | 1.5W |
| Heating Power |
2000W±10% |
| TDS |
50-1200PPM |
| PH | 2.5-11.2 |
| OPR | -800-500 |
| Water Pressure | 0.1-0.4Mpa |
| Continuous Electrolysis Time | 30mins |
|
Total Handling Water Capacity |
10000L |
|
Electrolytic Plate Material |
Taitanium with platinum coating |
|
Plate size |
15cm*9cm |
|
Numbers of plate |
8 |
|
Display |
3.8-inch seven-color LCD display |
| Net Weight | 10kg |
| Dimension(H*W*D-mm) | 380*280*175 |
Product Features
1. 24-hour time display, humanized design, warm reminding of cooking process, free control of time.
2. Microcomputer automatic control electrolysis, suitable for various water quality TDS=50-1200PPM.
3. Intelligent voice system, real-time prompt working status and gear function, convenient for users to use and operate.
4. The use of high power switching is suitable for power supply all over the world. It has low power consumption, high efficiency, constant current and constant voltage output, and ensures more stable and sufficient water quality.
