Product Description
Ultra-pure water is the water produced by distillation, deionization, reverse osmosis or other appropriate supercritical fine technologies for the development of ultra-pure materials (semiconductor original materials, nano fine ceramic materials, etc.). Its resistivity is greater than 18 m Ω *cm, or close to the limit value of 18.3 m Ω *cm (25 ℃)
Technical Parameter
| Type | basic analytical type |
| Model | OK-EP80 |
| AC Voltage | 110/220V,50/60Hz |
| Flow Rate | 1.5-2L/min |
| Output | 80L/h |
| Feed Water Requirements | tap water, temperature 10~35℃,pressure 0.15-0.35Mpa;TDS:≤200mg/L |
| Water Quality | |
| Pure Water | conductivity:2-10μs/cm@25℃ |
| Ultra-pure Water |
resistivity:18.25MΩ/cm@25℃, TOC:5-10ppb, bacteria: <1CFU/ml, particle: (>0.2μm) <1pc/ml |
| Application |
preparation of solutions, reagents, and buffers; vessel washing; physical and chemical testing and other routine quantitative and qualitative analysis. |
|
Dimension(L*W*H-mm) |
600*450*1000 |
|
Weight(kg) |
70 |
Application:
Preparation of solutions, reagents, and buffers; Vessel washing; Physical and chemical testing, and other routine quantitative and qualitative analysis.
Product Features
1. Microprocessor Control
A fully automatic and self-diagnostic system monitors and controls working conditions.
Two water quality sensors, consumables managements, system circulation, and disinfection function.
2. Ultra-purification Cartridge
Adoption of high-quality nuclear grade resin,US DOW, and Rohm Haas
Polishing cartridge removes ionic and organic contaminants below trace levels
3. Hollow Fiber Ultrafiltration
Filter design cutoff molecular weight of 5000 Daltons, removal bacteria, endotoxin, and fine particles to meet the user requirements for ultra-low endotoxin water.
4. High-strength UV lamp
Dual wavelength UV lamp 185*254nm ensures organic molecule oxidation and bacteria destruction.
Held in a robust and corrosion-resistant stainless steel housing.
